28 m3 Cement Bulker Semi Trailer
| Length | 10.050 mm |
| Height | 3750 mm |
| Width | 2550 mm |
| Volume of the Silo | 28 𝑚m3 |
| Body Material and Thickness | 4 mm Sheet Metal |
| Chasis Flat Bar Material and Thickness | 120x12 mm hot rolled steel |
| Chasis Sheet Metal Thickness | 4 mm Sheet Metal |
| Manholes | 10 mm cover, gasket including |
| Discharging line | Discharging valve both side of the trailer, 4 mt discharge hose is including |
| Landing Legs | OMS brand 25 ton dinamic, 50 ton static load capacity |
| Electrical system | 2x7 pin, lighting set is used.Turkısh brand 2 set 7-function rear taillights (horned), 2 pcs white led front lamps, 4 x 2 yellow led side lamps, |
| Air System | Turkish Brand |
| Compressor | Diesel Compressor including (Electrical is an option) |
| Brake System | Normal brake |
| Axles | 3 axle Sertel Brand |
| Standard Accessories | Storage cabinet , crom water tank, plastic mudguards, chock |
| Paint Process | After welding process the sandblast is applied on the trailer. After sandblasting, 2 primer paints and 1 final acrylic paint is applied. |
| Final Paint | The color can be choosen by customer. İf requested any logo or digits can be applied. |
The above-mentioned features can be changed in line with the customer's needs and wishes. If the customer specifies the features of the product they need, we can provide the exact value of the product they are looking for.
34 m3 Cement Bulker Semi Trailer
| Overall Length | 11.905 mm |
| Overall Height | 3970 mm |
| Overall Width | 2550 mm |
| Volume of the Silo | 34 𝑚m3 |
| Body Material and Thickness | 4 mm Sheet Metal |
| Chasis Flat Bar Material and Thickness | 120x12 mm hot rolled steel |
| Chasis Sheet Metal Thickness | 4 mm Sheet Metal |
| Manholes | 10 mm cover, gasket including |
| Discharging line | Discharging valve both side of the trailer, 4 mt discharge hose is including |
| Landing Legs | OMS brand 25 ton dinamic, 50 ton static load capacity |
| Electrical system | 2x7 pin, lighting set is used.Turkısh brand 2 set 7-function rear taillights (horned), 2 pcs white led front lamps, 4 x 2 yellow led side lamps, |
| Air System | Turkish Brand |
| Compressor | Diesel Compressor including (Electrical is an option) |
| Brake System | Normal brake |
| Axles | 4 axle Sertel Brand |
| Standard Accessories | Storage cabinet , crom water tank, plastic mudguards, chock |
| Paint Process | After welding process the sandblast is applied on the trailer. After sandblasting, 2 primer paints and 1 final acrylic paint is applied. |
| Final Paint | The color can be choosen by customer. İf requested any logo or digits can be applied. |
The above-mentioned features can be changed in line with the customer's needs and wishes. the customer specifies the features of the product they need, we can provide the exact value of the product they are looking for.
40 m3 Cement Bulker Semi Trailer
| Overall Length | 13.131 mm |
| Overall Height | 3980 mm |
| Overall Width | 2550 mm |
| Volume of the Silo | 40 𝑚m3 |
| Body Material and Thickness | 4 mm Sheet Metal |
| Chasis Flat Bar Material and Thickness | 120x14 mm hot rolled steel |
| Chasis Sheet Metal Thickness | 5 mm Sheet Metal |
| Manholes | 10 mm cover, gasket including |
| Discharging line | Discharging valve both side of the trailer, 6 mt discharge hose is including, 4’’ discharging hose on the left side, to the rear |
| Landing Legs | OMS brand 25 ton dinamic, 50 ton static load capacity |
| Electrical system | 2x7 pin, lighting set is used. Turkısh brand 2 set 7-function rear taillights (horned), 2 pcs white led front lamps, 4 x 2 yellow led side lamps, |
| Air System | Turkish Brand |
| Compressor | Diesel Compressor including (Electrical is an option) |
| Brake System | ABS brake system |
| Axles | 4 axle Sertel Brand |
| Standard Accessories | Storage cabinet, crom water tank, plastic mudguards, chock |
| Paint Process | After welding process the sandblast is applied on the trailer. After sandblasting, 2 primer paints and 1 final acrylic paint is applied. |
| Final Paint | The color can be choosen by customer. If requested any logo or digits can be applied. |
The above-mentioned features can be changed in line with the customer's needs and wishes. the customer specifies the features of the product they need, we can provide the exact value of the product they are looking for.
